PSOC™ Control C3P

The Next Generation of Microcontrollers for Power Conversion

anchor

Overview

PSOC™ Control C3P is Infineon’s newest MCU’s developed specifically for power conversion applications. Building on top of a real-time control Arm® Cortex® - M33 based core, this high-performance microcontroller family integrates advanced real-time analog peripherals to enable designers to improve efficiency and reliability of their new designs. Typical applications include telecom / server power supplies, light electric vehicle chargers, and solar inverters.

Key Features

  • Up to 180 MHz Arm Cortex-M33
  • Up to 256KB read-while-write flash
  • 64KB SRAM with ECC
  • 16KB I-Cache
  • 6 power modes with deep sleep
  • 12-bit, 12-Msps "Idle sampling" ADC
  • 16x16 bit and 4x32 bit TCPWMs
  • PSA L2 device security
  • NIST P256 & TRNG
  • Secure boot

Product Table

About

PSOC™ Control C3 Entry Line

Entry line of MCU will provide the best cost to performance ratio.  This is ideal for applications which still wants the performance from a Arm Cortex M33 core, but do not require the higher speed ADC or the HRPWM.

  • 100MHz Arm Cortex M33 with DSP and FPU
  • Memory up to 256KB flash, 64KB SRAM, 16KB I-Cache
  • Analog 12-bit, 6 MSPS SAR ADC
  • Real-time control, 16 x 16 bit and 4 x 32 bit TCPWM's, power conversion timers
  • Packages:  48 or 64 pins
PSOC™ Control C3 Main Line

The Main line of C3P will offer the best performance possible for high performance power conversion applications.  This is ideal for high efficiency and high power density SMPS or digital power supplies which plans to incorporate WBG switches such as SiC or GaN.  With the integrated 12-Msps ADC and <100 ps HRPWM, the Main line MCU will still have plenty of utilization headroom to perform other system functions as required.

  • 180MHz Arm Cortex M33 with DSP and FPU
  • Memory up to 256KB flash, 64KB SRAM, 16KB I-Cache
  • High performance analog 12-bit, 12 MSPS SAR ADC
  • Real-time control, 16 x 16 bit and 4 x 32 bit TCPWM's, power conversion timers
  • Packages:  48 or 64 pins

PSOC™ Control C3 Entry Line

Entry line of MCU will provide the best cost to performance ratio.  This is ideal for applications which still wants the performance from a Arm Cortex M33 core, but do not require the higher speed ADC or the HRPWM.

  • 100MHz Arm Cortex M33 with DSP and FPU
  • Memory up to 256KB flash, 64KB SRAM, 16KB I-Cache
  • Analog 12-bit, 6 MSPS SAR ADC
  • Real-time control, 16 x 16 bit and 4 x 32 bit TCPWM's, power conversion timers
  • Packages:  48 or 64 pins

PSOC™ Control C3 Main Line

The Main line of C3P will offer the best performance possible for high performance power conversion applications.  This is ideal for high efficiency and high power density SMPS or digital power supplies which plans to incorporate WBG switches such as SiC or GaN.  With the integrated 12-Msps ADC and <100 ps HRPWM, the Main line MCU will still have plenty of utilization headroom to perform other system functions as required.

  • 180MHz Arm Cortex M33 with DSP and FPU
  • Memory up to 256KB flash, 64KB SRAM, 16KB I-Cache
  • High performance analog 12-bit, 12 MSPS SAR ADC
  • Real-time control, 16 x 16 bit and 4 x 32 bit TCPWM's, power conversion timers
  • Packages:  48 or 64 pins
